KA189R109減速機銘牌參數說明解讀含義:有關型號描述的詳細情況及其他信息可以參閱本業附件下載中的KA189R109減速機選型樣本。
KA189R109-Y37KW-4P-193-M3-270°
KA/R:系列代號
189/109:減速機規格代號
Y:電機
37KW:電機功率
4P:電機級數
193:減速機傳動比
M3:減速機安裝位置
270°:接線盒位置
KA189R109減速機電機保養檢查:
KA189R109減速機電機一般檢查:定期檢查電機。檢查頻率取決于周圍空氣的潮濕程度以及當地的天氣狀況。可預先通過試驗確定,并嚴格遵守;保持電機清潔和自然通風。在多灰塵環境中使用電機時必須定期檢查通風系統并進行清潔;檢查油封的狀況,必要時應更換;檢查接線和安裝螺栓的狀況。齒輪減速電機
做一般定期檢查時,請需注意:溫度上升齒輪減速電機為F級絕緣,全密閉外扇構造,所以電機表面溫度比周圍高50°C左右即屬正常;如果溫度高于以上時,必須停機檢查(因素:電機或負載傳動系統異常)。
KA189R109減速機剎車電機剎車片因長時間使用會有磨損,請依據剎車間隙值進行調整(正常間隙值0.3~0.7mm)。
KA189R109減速機電機異常振動、噪音正常情況,本機幾乎沒有振動噪音。若有某些安裝異常使用,會產生振動噪音,所以請?zhí)貏e留意(當空載噪音值在70dB(A)/1M以下時,是被容許的);電機通風口有時會積聚雜物妨礙通風,所以請清除電機外部,以確保電機正常運行溫度;定期檢查時,請用兆歐表以500V測試電機繞組之絕緣阻抗,對地電阻應1MQ以上,以避免漏電之風險。
測定絕緣電阻時,請勿觸摸端子。否則有可能會導致觸電。減速電機工作時的表面溫度較高,請勿赤手觸摸。否則有可能會導致燙傷。請勿超出額定負載使用。否則有可能會導致受傷、裝置損壞。單相電機的啟動用電容器的通電部分,在未完全放電前請勿觸及。否則有可能會導致觸電。使電機反轉時,請務必暫停后開始反轉。否則有可能會出現旋轉方向未發生改變的電機失控。直角減速機
KA189R109減速機電機不轉解決方案:
電源未接通或接觸不良或電源電壓過低,排查維修;
過載跳閘,選擇大容量電機或減輕負載;
機械故障,檢查電機和傳動裝置是否可以自由轉動。檢查軸承和潤滑脂;
電機卡死,更換電機;
電源連接錯誤,核對接線是否與電機接線圖一致;空心軸減速機
定子繞組斷路,用萬用表歐姆檔檢查,若有相無電阻,則是此原因,確認后換線圈繞組;
定子繞組匝間短路,用萬用表歐姆檔檢查,若有相電阻與標佳值偏差夭于10%,則是此原因,確認后換線圈繞組;
定子繞組對地短路,用萬用表歐姆檔檢查,若線圈與機殼間有電阻小于1000歐,則是此原因,確認后換線圈繞組;
定子繞組接線錯誤,拆開電機找出錯誤,重新接線;
定子線圈的6引線接錯,換定子線圈。
KA189R109減速電機型號:
